FC200S Slurry AUTOMATIC PARTICLE CHARACTERISTIC ANALYZER FOR LIQUIDS AND SUSPENSIONS WITH A SPECIALLY DESIGNED SYRINGE PUMP FOR APPLICATIONS WHERE VERY PRECISE SAMPLING IS REQUIRED.

PARTICLE SIZE PARAMETERS: 200 nm to 10 CM
STANDARD CAMERA RESOLUTION: 6.6 MILLION PIXELS
PIXEL SIZE: 3.5 MICRONS
HIGH RESOLUTION CAMERA:10 MILLION PIXELS
PIXEL SIZE: 1.67 MICRONS
THIS EASILY MAINTAINED PARALLEL SLIDE FLOWCELL, CAN BE ADJUSTED FROM 50 MICRONS TO 1 MILLIMETER, WITH SPECIAL SPACERS, TO ALLOW FOR THE ACCURATE ANALYSIS OF MATERIALS DOWN TO 200 nm IN SIZE, SUCH AS  AGGREGATES.
SYRINGE PUMPS AVAILABLE FOR
 .1 ml TO 2.5 ml SAMPLING

NEW! STAND ALONE MEMBRANE PUMP ADD ON MODULE AVAILABLE FOR FC200S SLURRY
THE EASY TO USE CALLISTO SOFTWARE ALLOWS FOR ROBUST PARTICLE CHARACTERIZATION WITH THE CLICK OF A MOUSE, INCLUDING SEVERAL NEWLY DEFINED SHAPE PARAMETERS.
PARTICLE CHARACTERIZATION USING DIGITAL IMAGE ANALYSIS THEORY
FC 200S-CMP Slurry SYRINGE PUMP MODEL FOR
PRECISE SAMPLING APPLICATIONS 200 nm to 10 cm.
NEW ADVANCES IN HIGH RESOLUTION IMAGING!
CALLISTO SOFTWARE
FC 200S (SYRINGE PUMP)
THE FC200S-CMP SLURRY IS PART OF A FAMILY OF HIGHLY SOPHISTICATED DIGITAL IMAGING SYSTEMS, THAT ARE BY PRODUCTS FROM A SERIES OF COLLABORATIVE STUDIES IN LIGHT, OPTICS, AND SAMPLE TRANSPORT, CARRIED OUT WITH THE COOPERATION OF THE UNIVERSITY DE LIEGE IN BELGIUM.
NEW HIGH RESOLUTION IMAGING TECHNOLOGY

THIS HIGH RESOLUTION IMAGING TECHNOLOGY, IS ACCOMPLISHED IN PART, BY USING SPECIAL BACK LIGHTING TECHNIQUES FOCUSED FROM BEHIND THE SAMPLE. AN ADJUSTABLE RANGE, MONOCHROMATIC, BLUE LIGHT SOURCE HAS BEEN SHOWN TO PROVIDE OPTIMAL CONTRAST CONDITIONS FOR THE PARTICLES AND VIRTUALLY ELIMINATES DIFFRACTION. THE LIGHT IS COLLIMATED, AND ACTS AS A HIGH DEFINITION CALIPER.
OCCHIO FC200S-CMP Slurry PARTICLE CHARACTERISTIC ANALYZER FOR PARTICLES SUSPENDED IN LIQUID
MONOCHROMATIC COLLIMATED BACKLIGHT ACTS LIKE A CALIPER, AND PROVIDES RESOLUTION UNATTAINABLE WITH WHITE LIGHT OR LASER DIFFRACTION
TELECENTRIC LENS- IMAGE MAGNIFICATION IS INDEPENDENT OF THE OBJECTS DISTANCE OR POSITION IN THE FIELD OF VIEW
SAMPLE SUBMISSION FORM
BILL TO INFORMATION:
Email Address
First Name
Zip or Postal Code
Company
Telephone
Last Name
Street Address Line 1
Street Address Line 2
INFORMATION REQUEST
QUOTATION REQUEST (FILL IN APPLICABLE FIELDS FIRST)
Notes
PARTICLE AGGREGATION AT 300 NM (CTRL + TO ZOOM PAGE)
CALLISTO SOFTWARE PROVIDES: PARTICLE COUNTS BY mL, PARTICLE SIZE ANALYSIS, MORPHOLOGY ANALYSIS, FILTERING CAPABILITIES, MORPHOLOGICAL PARAMETERS, EXPORT TO TEXT AND EXCEL.
CMP SLURRY ANALYSIS: AGGREGATE DETECTION

IN ORDER TO AVOID SCRATCHING ON GLASS SURFACES, IT IS CRUCIAL
TO CHECK A CMP SLURRY BEFORE POLISHING.

THE PARTICLE COUNTER ALLOWS THE DETECTION OF AGGREGATES IN THE SUSPENSION THAT ARE SCRATCHING THE GLASS.

BECAUSE IT USES DIGITAL IMAGING, THE FC200S CMP SLURRY IS UNIQUE IN THAT IT CAN DETECT VERY SMALL AMOUNTS OF PARTICLES IN SUSPENSION.
OCCHIO INSTRUMENTS CAN BE USED UNDER A FUME HOOD. THE SLURRY ALSO HAS A 3-WAY SYRINGE PUMP, BK7 GLASS SYRINGE, WIDE FLOW RATE RANGE, TEFLON TUBING. THE SLURRY IS COMPATIBLE WITH DLS AND 4F.
SPECIAL SYRINGE PUMP FOR PRECISE SAMPLING.

Copyright 2012: QAQC Lab | Particle Measurement System | All rights reserved.
866-244-1578 | support@occhio-usa.com
www.occhio-usa.com
PARTS AND ACCESSORIES
BROCHURE FC200SCMP
DIGITAL IMAGING EQUIPMENT FOR PARTICLE CHARACTERIZATION IN LIQUIDS AND POWDERS
INSTALLATIONS WORLDWIDE
HOMECONTACT USPRODUCTS

OCCHIO DIGITAL IMAGE ANALYZERS HAVE THE ABILITY TO DETECT AND QUANTIFY BOTH PARTICLE SIZE AND PARTICLE SHAPE, PAVING THE WAY FOR THE ADVANCED ANALYSIS OF PARTICLES IN BOTH LIQUID AND SOLID FORMS.

CORRELATIONS TO OTHER PARTICLE SIZE ANALYSIS METHODS, LIKE SIEVE ANALYSIS AND LASER DIFFRACTION, ARE SEAMLESSLY EMPLOYED. EVEN SHAPE PARAMETERS LIKE LENGTH, FLATNESS, AND ANGULARITY IN AGGREGATES, OR THE LENGTH OF STRINGY PARTICLES LIKE SHREDDED CHEESE, OR TOBACCO, ARE POSSIBLE.

ONCE A BASIC CORRELATION HAS BEEN ESTABLISHED, THE RESULTS ARE FINE TUNED WITH THE OCCHIO CORRELATION PROGRAM, ALLOWING FOR TURNKEY SOLUTIONS TO PARTICLE CHARACTERIZATION.
